Several standard tie bar fittings are used, either to connect  tie bars to make longer lengths or provide articulation. Special fittings allow both connection of tie bars and articulation. All SHENLI fittings are designed to exceed the capacity of the tie bar and where required have a sacrificial steel allowance.


                         Turnbuckle                                                       Joint plate1

                     Couplers and turnbuckles are used to connect tie bars to make                                          Articulated turnbuckle allows tie bars length adjustment and
                     longer lengths. A turnbuckle can be used for length adjustment.                                         articulation in one plane of the tie bar.


                 Joint plate                                 PLATES2


             Together with forged eyes link plates provide the most economic                           Cardan joint  allows tie bars with forged eyes to articulate in both
             articulated joint and the simplest tie bar connection to achieve in                            vertical and horizontal planes.
             site conditions
